Details
The DUAL LIMITER has a unique design that will enhance the sonic textures of your audio system for years to come. Developed in partnership with studio and live-sound engineers, the DUAL LIMITER is very musical.
The heart of the Dual Limiter is a unique PWM gain control circuit. Combined with its’ intelligent detector, the result is a Classic sounding compressor/ limiter without the traditional noise and distortion artifacts.
Features:
- Two channels of dynamics processing
- Selectable stereo linking of channels
- XLR balanced inputs and outputs
- 1/4″ TRS active balanced inputs and outputs
- Variable Attack and Release controls
- Selectable Slope
- Hardwire bypass
- 5-segment Gain Reduction LED array
- Internal power supply
Specifications:
| Equivalent Input Noise | -97dBu (20-20kHz) |
| Input Impedance | 20k Ohms |
| Output Impedance | Balanced/Unbalanced – 150 Ohms |
| Maximum Input Level | +20dBu |
| Maximum Output Level | +20dBu |
| Overall Gain | +40dB max |
| Frequency Response | 10Hz to 30kHz (+/- 1dB) |
| Dynamic Range | >105dB (20-20kHz) |
| Attack Time | 0.5mSec. to 50mSec., variable |
| Release Time | 100mSec. to 3 Sec., variable |
| Slope | 4:1 or >20:1, switchable (OR 2:1 or 1.5:1 when patching output to det. loop input) |
| Total Harmonic Distortion | 0.03% (typical) @ 0dBm Out |
| Power Requirements | USA – 105 to 125 VAC / 60 Hz, 1/2A fuse, <15W Export units configured for country of destination. |
| Dimensions | 44.5mm x 482.6mm x 150mm |
| Weight | 2.1 kg |
