ART USB Mix 4

$269.99

SKU: ARTP_USBMIX4CE Categories: , , Tags: , ,

4-Channel Mixer with USB Interface

FacebookTwitterPinterestLinkedin

Description

The ART USB Mix 4 is a great starting point for building a personal home studio. Perfect for podcasters, songwriters or at-home movie makers looking for a simple solution for recording voiceovers, location recording or adding music to your projects using any Mac or PC.

Features

  • Powered by USB from your computer or via USB power adapter (included)
  • CH1 and 2 Microphone (balanced XLR) inputs or instrument (unbalanced 1⁄4-inch TS) inputs with switchable impedances
  • Switchable low noise +48V phantom power for microphones
  • Balanced 1⁄4-inch TRS inputs for stereo or mono line-level sources on CH3
  • 1⁄4-inch TRS output jacks work with balanced or unbalanced lines
  • 3.5mm TRS stereo Aux/MP3 input
  • Stereo output, independent from the PC interface switch
  • Stereo 1⁄4-inch TRS headphone jack with independent level control for output monitoring
  • Independent controls for both sets of inputs, main output, and headphone monitor
  • Red LED signal/clip indicator for Ch1-2
  • No special drivers are needed with most modern versions of Windows or Mac OS and Linux
  • USB cable, USB power adaptor and Audacity recording software included
  • Rugged steel chassis

APPLICATIONS

This compact 4-channel audio mixer with USB interface is suited for universal applications, e.g. for audio recording on the computer. The mono input channel allows connecting a (phantom-powered) microphone; the stereo input channel allows connecting an audio source with line signal level. In addition, the mixer is provided with connections for a recorder and headphones. The mixed signal is sent to the output via 1⁄4-inch jacks and the USB port. It is also possible to use the USB port as an input to transfer audio data from the computer to the mixer. When connecting the mixer to a computer, power is supplied via the USB connection. When operating the mixer without a computer, either use a suitable power supply unit with USB connection to operate the mixer.

Specifications

Input Connections  XLR & ¼-inch Balanced Combi-jack (CH1 & CH2)
¼-inch TRS Balanced (CH3 & CH4)
3.5mm TRS Aux/MP3, 1/8-inch Headset Mic
Output Connections  ¼-inch TRS Balanced Main Mix Outputs
¼-inch TRS Stereo Output & Monitor Outputs
3.5mm Headset Output
Signal to Noise Ratio  >90dB Typical (Ref 0dBu)
Maximum Input Level  +8dBu (Mic), +16dBu (1/4-inch Input)
Maximum Output Level  +15dBu Main Mix Outputs
Maximum Gain  >55dB (Mic), >37dB (Instrument), 5dB (CH3 & CH4)
USB Computer Interface  USB Class Compliant plug-and-play Mac / PC Interface
Power  Via USB or 5VDC @ 500mA
Dimensions  H 45mm x W 130mm x D 191mm
