ART S8 eight-channel rackmount preamp, front view showing XLR inputs and controls on black faceplate

ART Technology

ART S8

SKU: ARTP_ARTS8

AUD RRP $649.95 Inc GST*

Limited stock — call to check

Ask your local dealer for a deal!

Find a dealer
The S8 lets your signals be in two places at once. It's an 8-channel splitter in a 1U rackmount enclosure, with one direct output and one transformer-isolated output per channel. The passive design doesn't require power, but the direct outputs will pass phantom power for use with active microphones. Each channel also features a switchable ground lift on every channel to reduce noise due to ground loops, and an input pad to accommodate line level sources. When two outputs are better than one, use the S8 to connect to both the front-of-house and monitor mixers, for creative parallel processing, or to record safety tracks at lower levels in case of clipping. Need more outputs per channel? Check out the S8-3Way.

Learn more directly from ART Technology's website →

Features:

  • 8-Channel 2-Way Splitter
  • Balanced XLR Connections
  • 1x Direct and 1x Transformer-Isolated Output per Channel
  • Direct Outputs Pass Phantom Power
  • Switchable Ground Lift and Input Pad per Channel
  • Passive Design - No Power Required
  • 1U Rackmount
  • Reversible Rack Ears

Specifications:

Input Impedance > 1.1k Ω @ 1kHz (Typical)

Maximum Input Level -1.4dBu @20Hz / +3.5dBu @30Hz / +9.4dBu @50Hz

Output Impedance <255 Ω @ 1kHz (Typical)

Total Harmonic Distortion <0.1% From 45Hz To 20kHz @ -15Dbu Input

Frequency Response 20Hz to 20kHz

CMRR > 105dB @60Hz / Greater Than 80dB @3kHz

* All pricing and stock availability are subject to change at any time without notice
